Turnbuckle Weld-On End M8.
Turnbuckles are a handy tool used to adjust the tightness or length of ropes, cables, and other tensioning systems. They typically consist of two threaded eye bolts screwed into a central body. Crucially, one eye bolt has a regular right-handed thread, while the other has a left-handed thread. By rotating the body itself, you can screw both eye bolts in or out at the same time, without twisting the cables attached to them. This allows for precise adjustments in tension.
Open Housin Smooth Ends For Self Welding Of Attachements (Eyes, Points,Hooks).
Working Range: 240 - 315 mm.
Head Type Connection No 1: Stub.
Head Type Connection No 2 : Stub.
Thread Diameter: M8.
Breaking Load: 960 kgs.
Safe Work Load Capacity: 140 kgs.
DIN Standard: 1480.
Total Length: 240 mm.
Body Inside Length: 75 mm.
Body Outside Length: 110 mm.
| Manufacturer | KRAMP |
|---|
